使用与介简/Brief Introduction：

机器组为10-20ml胶囊液液态装灌设配产生加工线中的通常设配。是由洗瓶、晒干成移动教学分离式机和装灌设配密封成移动教学分离式机所组合而成，能自己完成胶囊液瓶的洗瓶、晒干、装灌设配和密封等操作，是胶囊液产生加工产家更很理想的配置设配，完成合适GMP规范。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

优缺点/Characteristic：

◆装量明确，应对滴漏问题。包装精准更高。High filling accuracy.◆变频式无及调速器，制作时间随意调节，供选择择有所不同的制作时间。Frequency control, production speed is adjustable, you can choose a different production rate.◆其他电元器件封装均进行国外知名度高口碑好国产品牌。All electrical components are imported famous brands.◆智能体现计算效果。Automatically countting function.◆调整用日本队三凌PLC，抗干扰信号，操作不稳。Controlled by Mitsubishi PLC◆安全性能平稳，维持护理不方便。Stable performance, easy maintenance.◆整个设备相貌进行SUS304不锈304冷库保温隔热板的表层作、与原辅材料接受个部分进行316L304冷库保温隔热板的表层。整个设备充分按GMP耍求的设计。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

方法参数值/technical parameters：

适宜规模/Bottle size	10-20ml
产量技能/Capacity	60-90瓶/30分钟/60-90bottles/min
吹干湿度/Dryer tempreture	100-300°
使用水访问量量/Water wastage	0.5m3/h
空气净化水耗量/Purifying water consumption	0.3m3/h
装量精度等级/Filling precision	≤1%
电源开关/Voltage	380V/50Hz
输出/Power	33KW
生产的线总长/Dimension	3500×1500×1600mm
