用处与简洁/Purpose and introduction：

NQGF型西林瓶粉针洗烘分开包装轧盖标贴联动机制线 由QCL类型立柱式超声心动图清晰波洗瓶机、AQMR隧洞式自动空调再循环法杀菌处理烤箱、NQFGX类型数控内外螺杆式粉剂分开包装机、NQ-50轧盖机、NQWTB-120标贴空气能机组成，也可电脑单机选择。适于于7-25ml型号规格的西林瓶粉针的制作。能达成喷淋清晰加压、超声心动图清晰波粗洗、瓶表面水清晰、瓶表面接连首次再循环法水清晰、以此吹气、以此剥好水清晰、接连首次吹气、瓶表面吹气、清晰、点火、吹干杀菌处理去热原、冷却塔、分开包装、加塞、轧盖、标贴等二十来道工序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

性能/characteristic：

◆洗瓶机使用机制手夹瓶，使用好几种标准的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶分为水汽喷针往复式跟踪目标复制方试，难以清理性能好好，厉行保护生态环境资源。并应设针架防颤动设施，提高自己喷针复制水瓶座的最准度，极大减少断针物理现象产生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶一部分气水管道、喷针根本独立空间分类建立，禁止了对称空气污染，遵循GMP规范标准的标准；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶挤出机螺杆式前加裝抗震块，有自我保护挤出机螺杆式，限制碎瓶用处；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶选择产品 进口的同步操作带，相连接拨瓶块输料西林瓶，电脑运行安全稳定可信度；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆烤箱利用内反复反复热处理加热，环境温度均匀的，环保；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆恒温干燥箱可设防显得突然停电护理作用。运作安全卫生；Mixer oven has suddenly loses power protection function. Run security;◆真空烘箱可配循坏水冷散热器控制系统，不耗损率房間风速，减小房間的压力不均衡的危险因素变凉效用好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆烘干箱可配压力半自动取舍调装置减低房屋和烘干箱的压力不取舍出现的高溫段偏斜，装灌间洗烘间的温度升高等专科学校一系类的困难；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆真空烘箱现有DOP测量界面(其中包括气压、流速、尘沙再生颗粒测量口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆烘烤箱保压段可带线上高压蒸汽灭菌特点(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烤箱网带可带超声检查牵连CIP免费在线拆洗系统软件；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆恒温干燥箱内腔室可展开全东南方向、多层面超高压水洗；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆包装机使用国际上更最新的设置核心价值，有着高极限速度度，且分瓶最准确，撤换规格型号件更方便；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆散装机通过沟通交流伺服无刷电机无刷步进电机控制器散装丝杠补偿器，装量精度；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆分开包装机利用装量的变动立即在摸屏上控制；Mixer packer adopts the load adjustment directly on a touch screen;◆灌装机先选配百级循环法式层流罩；Mixer packer optional circulating laminar flow hood best level;◆包装机无瓶停下包装，无瓶没有塞功能表。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线选取PLC总掌控、变频式器、接触屏掌控新技术，电脑自动正常运作靠谱靠谱。接触屏可显现各单机联机的电脑自动正常运作状况，各掌控点的通水压力、空气压力、压力、温等显现，各管理开关状况和系统设备故障问题显现，系统设备故障问题自我管理测试和系统设备故障问题研究分析及检测方法步骤。使整个的加工工作到达电脑机械自动化掌控，联线有测控平衡量器，提高加工教育均衡发展靠谱。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.会按照用户的要有，还可供配置：According to the needs of customers, but also available for selection:◆PLC、斯耐德、西门子、台达等国际品牌调节整体；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气负担、水温表及超声心动图波力度、埃尘塑料再生颗粒、风力迅雷在线查重、報警、记录查询、缩印系统化；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、没有细菌防护隔离器平台。ORABS, CRABS, aseptic isolator system.

的技术性能参数：/technical parameters

型号规格 model

生孩子力量production capacity

洗瓶及格率率Washing bottle percent of pass

洗瓶已经破损率Washing bottle breakage

杀菌温湿度sterilizing temperature

分开包装误差率The repackaging of error

加塞达标率Gasser percent of pass

自然空气层流洁钻石净度度Laminar air cleanliness

真空环境抽速Vacuum pumping speed

电阻量 capacitance

电源模块power supply

总电能Total transmission energy

外型尽寸boundary dimension

7-25ML新国标西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
